CommScope SYSTIMAX CPCC3312-02F007 Cat6 RJ45 to RJ45 Patch Cord, 24 AWG Stranded Copper, 7ft (2.1m), Light Blue Ethernet Network Cable
SKU: CPCC3312-02F007
Category: Networking Products
Availability: 1000
Tag: commscope patch cord commscope systimax patch cord commscope cpcc3312-02f007 systimax cat6 patch cable cat6 ethernet cable rj45 to rj45 patch cord rj45 network cable black ethernet cable 24 awg stranded copper cable utp patch cord cat6 lan cable gigabit ethernet cable high speed network cable network patch lead copper ethernet patch cable structured cabling solution data networking cable cat6 rj45 cable commscope network cable systimax network accessories office network cable server rack patch cord switch to patch panel cable router ethernet cable lan patch cable black enterprise network cable professional ethernet cable 4 pair utp cable tia cat6 compliant cable network infrastructure cable black rj45 patch cable cat6 copper patch cord ethernet patch lead high performance patch cord networking accessories data center patch cable commscope ethernet cable systimax rj45 cable cat6 utp ethernet cord black network patch cord.
Quantity:
Description
The CommScope SYSTIMAX® GigaSPEED XL® Cat 6 U/UTP Patch Cord is a high-performance networking cable designed to deliver reliable Gigabit Ethernet connectivity for enterprise, commercial, and data center environments. Engineered to meet ANSI/TIA-568.2-D and ISO/IEC 11801 Class E standards, this patch cord ensures superior transmission performance for voice, data, video, and Power over Ethernet (PoE) applications.
Featuring stranded tinned copper conductors, gold-plated RJ45 connectors, and a durable PVC jacket, the patch cord provides excellent flexibility, durability, and long-term reliability. It fully supports IEEE 802.3bt Type 4 PoE (up to 90W) applications and is tested for over 3,000 plug-to-jack mating cycles, making it ideal for high-density network installations.
Available in multiple lengths and color options, the GigaSPEED XL® Cat 6 patch cord offers easy network organization while maintaining exceptional performance for switches, routers, servers, patch panels, and workstations.
Product Specifications
Brand: Commscope
Model Number: CPCC3312-02F007
Availability: In stock
Minimum order quantity: 1
Maximum order quantity: 10
Listed date: 17th Jun, 2026
Specifications
Product Information
| Specification | Details |
|---|---|
| Brand | CommScope |
| Portfolio | SYSTIMAX® |
| Product Brand | GigaSPEED XL® |
| Product Series | CPC / UTG |
| Product Type | Twisted Pair Patch Cord |
| Regional Availability | Asia, Australia/New Zealand, Latin America, North America |
| Category | Cat 6 |
| Cable Type | U/UTP (Unshielded Twisted Pair) |
| Transmission Standards | ANSI/TIA-568.2-D, ISO/IEC 11801 Class E |
| Wiring Scheme | T568B |
| Number of Pairs | 4 |
Connector Specifications
| Specification | Details |
|---|---|
| Connector A | RJ45 Plug |
| Connector B | RJ45 Plug |
| Connector Type | Standard RJ45 |
| Contact Plating | Gold over Nickel |
| Plug Contact Material | Phosphor Bronze |
| Plug Housing Material | Clear Polycarbonate |
Cable Construction
| Specification | Details |
|---|---|
| Conductor Material | Tinned Copper |
| Conductor Type | Stranded |
| Compatible Conductor Gauge | 24 AWG |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Cable Diameter | 5.97 mm (0.235 in) |
Available Colors
- Black
- Blue
- Dark Gray
- Green
- Light Blue
- Lilac
- Orange
- Red
- Spring Green
- White
- Yellow
- Purple/Violet
Electrical Specifications
| Specification | Details |
|---|---|
| Maximum Contact Resistance | 20 mΩ |
| Maximum DC Resistance | 0.3 Ω |
| Insulation Resistance | ≥ 500 MΩ |
| Dielectric Withstand Voltage | 1000 Vac @ 60 Hz |
| Current Rating | 1.5 A @ 20°C (68°F) |
| Safety Voltage Rating | 300 V |
PoE Performance
| Specification | Details |
|---|---|
| PoE Support | IEEE 802.3bt Type 4 |
| Maximum Power Delivery | Up to 90 W |
| Remote Powering | Fully supports IEEE 802.3bt safe power delivery |
| PoE Durability | > 3,000 plug-to-jack mating cycles |
Mechanical Specifications
| Specification | Details |
|---|---|
| Minimum Plug Retention Force | 50 N (11.24 lbf) |
| Mating Cycle Standard | IEC 60603-7 Series |
Environmental Specifications
| Specification | Details |
|---|---|
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Environmental Space | Non-Plenum |
| Flammability Rating | UL 94 V-0 |
| Safety Certifications | Anatel, ETL, cETL |
Dimensions & Length Options
| Specification | Details |
|---|---|
| Length Range | 1 m – 30 m |
| Length Range (Feet) | 1 ft – 100 ft |
| Length Range (Centimeters) | 15 cm – 999 cm |
| Length Range (Inches) | 6 in – 999 in |
Packaging
| Specification | Details |
|---|---|
| Packaging Quantity | 1 Piece |
Quality Compliance
| Certification | Details |
|---|---|
| ISO 9001:2015 | Designed, manufactured, and distributed under a certified quality management system |
